Cable fairing is a structure attached to a towed cable designed to streamline the flow around the cable, primarily in marine environments.

Cables are faired primarily for two reasons: (1) to reduce normal drag and thus achieve more depth for a given cable scope and speed; and (2) to eliminate cable vibration caused by vortex shedding, commonly known as cable strum.[1]There are several major types of cable fairing:
Hard fairing: essentially a streamlined teardrop-shaped shell clamped in sections over the cable;[2]
Ribbon fairing: flexible ribbons attached to the cable that assume a streamlined shape when towed;[3]
Hairy fairing: similar to ribbon fairing, but the “ribbons” take the form of hair-like flexible structures.[4]
All cables (faired or unfaired) have hydrodynamic loading functions.[5] These describe the variation in drag coefficient as a function of angle  with respect to the flow. As an example, the loading function for the normal drag coefficient of an unfaired cable, represented as a flexible circular cylinder, is sin2. ( = 90 degrees means that the cable is normal to the flow.)Fairing a cable can increase the complexity of the handling system. An unfaired cable can be wrapped many times on a winch drum. Some types of faired cable may only permit a single wrap.[citation needed]
Furthermore, many types of hard fairing require the use of anti-stacking rings.[6] When under tension, the diameter of a steel-armored cable gets smaller. This in turn would cause the fairing sections to loosen and slide down the cable (until they “stack” at the aft end) without the use of the anti-stacking rings.[citation needed]
